Count the people who clean at the same time, not the number of Satellites. A Satellite only draws water while someone is using it, so one pipe can feed more stations than the Booster is rated for.
Single pump
27 bar Boosters.
One Grundfos IE5 pump for one line or one hall. Feeds 1 to 9 Satellites at 27 bar, from 50 to 270 L/min.
Six sizes. One pump.
The same Booster, scaled by flow. Pick the size that matches how many people clean at the same time.
F, C
B 050-27
For a single cleaning point.
Users: 1
Flow: 50 L/min
Pressure: 27 bar
Versions: F / C
Pumps: 1 Grundfos IE5
Item no. (F / C): 7012000 / 7012001
F, C
B 065-27
Two Satellites on one pump. Small halls and single lines.
Users: 2
Flow: 65 L/min
Pressure: 27 bar
Versions: F / C
Pumps: 1 Grundfos IE5
Item no. (F / C): 7012002 / 7012003
F, C
B 100-27
Three Satellites. A line with its own crew.
Users: 3
Flow: 100 L/min
Pressure: 27 bar
Versions: F / C
Pumps: 1 Grundfos IE5
Item no. (F / C): 7012004 / 7012005
F, C
B 120-27
Four Satellites. The usual choice for a mid-size hall.
Users: 4
Flow: 120 L/min
Pressure: 27 bar
Versions: F / C
Pumps: 1 Grundfos IE5
Item no. (F / C): 7012006 / 7012007
F, C
B 200-27
Six Satellites across two lines.
Users: 6
Flow: 200 L/min
Pressure: 27 bar
Versions: F / C
Pumps: 1 Grundfos IE5
Item no. (F / C): 7012008 / 7012009
F, C
B 270-27
Nine Satellites. The largest single pump before multi pump.
Users: 9
Flow: 270 L/min
Pressure: 27 bar
Versions: F / C
Pumps: 1 Grundfos IE5
Item no. (F / C): 7012010 / 7012011
F, C or both
Foam or chemical. You choose.
Every size comes in two versions with the same pump, frame and pressure.
F for floor
Built for foam cleaning and rinse. Thick foam that clings to every surface.
C for cabinet
Built for chemical dosing and rinse, straight from the hose.
Same pump in both
One Grundfos IE5 pump, the same frame and 27 bar, whichever version you pick.
How do I choose the right size?
F stands on the floor and C sits in a closed stainless steel cabinet. The pump and pressure are the same in both.
When should I choose multi pump instead?
Above nine people cleaning at once. The multi pump range runs from 400 to 1080 L/min for 12 to 36 users.
What water supply does it need?
Ordinary tap water. If the mains cannot keep up, a pre-pressure Booster in front of it raises the inlet pressure.
Not sure which size?
Let's size it together.
Tell us how many people clean at once and how far the water travels. We will tell you which Booster fits, and what it would cost.
